Product name:Large Industrial High Temperature Ovens

Model Number: IR-DB300

Large Industrial High Temperature Ovens
Parameter:
1: Power:-phase 4-wire, 380 V, 50Hz;
2: Power Rating: 2 to 35 KW;
3: Rated temperature: Room temperature to 200.C;
4: Warming: Rated temperature to room temperature 25 minutes
5: Furnace temperature:+_5.C;
6: Heating method for heat conduction
7: Machine inner size:1100(deep)*3100(width)*1900 (height)mm
8: Machine Outter Dimension:1200*3700*2360mm
9.Packing Size:128*378*252CM
10:Net Weight:1200KG
11.Gross Weight:1500KG
Features:
1: The cabinet is made of composite materials, stainless steel and galvanized inner, filled with insulation materials with
good insulation effect.
2: Equipped with imported insulation materials, high accurate temperature control and wide temperature ranges
3: Equipped with exhaust tunnel for easy eliminating the air inside the cabinet.
4: The good design hot air circulation system for assuring substrate being dried and heated evenly.
5: Equipped with ultra-high-temperature alarming system, with safety explosion -proof door on the backend, beyond the
standard pressure will bounce automatically
