Infrared Drying Tunnel For Bottle

  • Model Number: M-400BO
  • Product price: US$:negotiated
  • Category: Drying Oven
  • Views: 5392
  • Product Description:Infrared Drying Tunnel For Bottle
  • PRODUCT DETAIL
  • Video

Product name:Infrared Drying Tunnel For Bottle

Model Number: M-400BO

Infrared Drying Tunnel For Plastic and Glass Bottle
Technical Parameters:
1:Model No:         M-400BO
2:Conveyer size: width: 400mm; infeed&outfeed length:500mm; heating zone: 2000mm*2 zones; total length at 5 meters;Max.infeed height at 28CM
3:Total wattage:   12KW
4:Circulating air motor :550W*2=1100W
5:Conveyer motor wattage:160W;velocity rate:50RPM,every 70 seconds
6:Heating temparature:100-200 degree; Heating tube length:450mm*24pcs;tubes power rate: 400W
7:Conveyer Speed adjustment: Stepless 0-8meters/minutes; Stainless steel conveyor belt
8:Machine dimension:  620mm width*5000mm length *1900 height(lxwxh)
9:Gross/Net weight:    980KG/900KG
10:Package:  Wooden case
11:Automatic Grade:  Manual
12:Warranty       :  2years
13:Usage:  Round,Oval and flat plastic or glass bottles
14:packing size:  512*81*175CM
15.Machine Size: 504*73*160CM
Package:               Export polywood case
Automatic Grade: Manual
Warranty       :      2 years
Usage:                  Round,Oval and flat plastic or glass bottles
Application
The machine is suitable for drying and curing the round, oval plastic or glass bottles. It is widely used in the cosmestic, house hold product bottles final step printing curing. The tooling holder is removable so it is also suitable for flat products curing.Advantages
1. Conveyer Made by stainless steel and high temperature resist ,
2. Famous brand motor drive,stepless speed adjustment.
3. High quality automatically temperature controlling system.
4. Fast drying for products after printing.
Product Description:
Fast drying after pad printing, screen printing, painting by solvent ink ; stepless transmission speed adjustment to match with printing request; invariablenes temperature controlling ensure production quality.
Infrared Drying Tunnel For BottleInfrared Drying Tunnel For BottleInfrared Drying Tunnel For Bottle
