Rotary automatic heat transfer machine

  • Rotary automatic heat transfer machine
  • Rotary automatic heat transfer machine
  • Model Number: AHT-6S
  • Product price: US$:negotiated
  • Category: Heat Transfer Machine
  • Views: 113
  • Product Description:Rotary automatic
  • PRODUCT DETAIL

Product name:Rotary automatic heat transfer machine

Model Number: AHT-6S

Parameter:
1:Mechanical model: AHT-6S
2: Turntable size: 700mm diameter
3: Stroke of hot stamping head: 80mm (adjustable 50mm)
4: Hot stamping temperature: room temperature 0 ℃ ~ 300 ℃
5: Rated voltage: 220v60 / 50Hz
6: Hot stamping pressure range: 250-300kg
7: Heating power: 2000W
8: Overall power: 3800w
9: Air pressure: 5-7bar
10: Machine size: 1400 * 1000 * 2100mm
11: Machine weight: 800kg
Features:
(1) Six station divider is adopted;(could be customizing according to samples size)
(2) Computer control, man-machine interface, easy to operate;
(3) Hot stamping pressure, temperature and speed can be adjusted;
(4) Built in self counting;
(5) Automatic foil feeding, foil winding and adjustable,
(6) The height of the hot stamping head is adjustable and the range is large;
(7) Manual feeding and automatic discharging;
