Syringe Automatic Silk Screen Printing Machine

  • PRODUCT DETAIL

Product name:Syringe Automatic Silk Screen Printing Machine

Specifications:
Shape of Pinted Objet:Cylindercal
Printed Object Dimension:Dia:5mm-75mm L:20mm- 230mm
Max. Speed:6000 PCS/Hr
Air Pressure:6-8 Bar
UV Lamp Power:5KW
Power Supply:AC380V 3 Phase 50HZ
Dimension:3370*1400*2300mm(L*W*H)
Weight:2650KG

Introduction

1.Specially designed for fast speed screen printing on circular objects, such as tubes, bottle caps, centrifuge tubes, centrifugal pipes, condenser tubes,
shake tubes, syringes, cosmetic jars and so on. And also can achieve multicolour printing and precise color register.
2.Main drive system uses transmission equipment of famous brand from Europe with precise high-speed indexer, so that it can make operations more
stable and reliable. The maximum printing speed can reach up to 6000pcs/hr.
3.Equipped with world famous PLC controller and convenient touch screen, therefore the whole operation becomes easy and simple.
4.Printing ink can be solidified by UV curing, UV LED curing or infrared drying, and gain more ideal solidification effect on the base of ensuring stable
performance and power saving.
5.Be provided with automatic monitoring function such as ionic wind dedusting,"no object, no printing" , automatic alarm due to low air pressure and
waste or wrong material, etc.
6.With automatic loading and unloading systems, not only ensure continuous and stable printing operation,
but also avoid scratching surface of printed
object during printing process and guarantee operator' s safe operation.

Optional Configuration (According to customer’s requirement)
1.Automatic feeder (bowl vibrating/ifting system, can save manpower and realize fully automatic production)
2.Automatic Capping System (for centrifuge tubes, condenser tubes; can save manpower and realize fully automatic production)
3.UV LED system (higher efficiency, more environmental-protection)
4.Automatic silicone oil injection system (for syringes)
5.Servo & Cursor Positioning System(can achieve precise color register for offset printing and hot stamping)
Mechanical positioning device (can realize multi-color overprinting)
6.Transformation function between screen printing and hot stamping
7.The main structure design of this machine is more reasonable, and it has made major optimizations than the existing domestic machines, and can
achieve stable and efficient production
